Product features include:
- Patented Direct Servo technology
- Hypex Ucd module-based amplifier with toroidal power transformer and two large 12000uF/80V capacitors
- 15″ black anodized aluminum high excursion driver
- Solid and very inert enclosure with multi-tune feature
- Bass extension control allowing adjustment of bass extension and excursion control
- Selectable 12/24 db/octave crossover filter slope
Direct Servo technology
All our subwoofers feature our Direct Servo technology, which is our secret to achieving tight and accurate bass. The benefits are far more than simply achieving low distortion.
15″ black anodized aluminum high excursion driver
Driver features include:
- Rigid silver anodized aluminum cone ensuring control at high SPL
- Low moving mass to ensure an exceptional transient response
- High flux density in the gap to ensure low distortion
- Flux de-modulation shorting rings to lower inductance and improve linearity
- Extended upper bandwidth response allowing a higher crossover point than most
Quality enclosure
Our enclosures are very solid and well braced to minimize any cabinet resonances or coloration. The baffle into which the driver is mounted is double thickness.
Bass extension controls
The bass extension control in FVX15 enables the user to customize the frequency response of the low end. It combines multi-tune specific frequency contouring and damping control in one switch. The damping control determines the slope of roll-off and the amount of time domain ringing. High damping provides the least amount of time domain ringing and the most gradual roll-off curve. Low damping provides the steepest roll-off at the low end at the expense of added time domain ringing. There are two positions for 1 port operation which extends to 12hz. 1P-music uses high damping while 1P-HT uses low damping. High SPL playback should use 2 port setting. The damping in this position is low.
Crossover options
To suit different setups, we provide a 12 db and 24 db/octave crossover. If you are still using stereo receiver or conventional pre/power amp setup, then we recommend the 24 db switch setting.
Integration
One important aspect of getting a correct integration is phase alignment.
